| Nguồn gốc: | Trung Quốc |
| Hàng hiệu: | XZH Test |
| Chứng nhận: | CE/ISO |
| Số mô hình: | XHCC-4/30 |
In the world of electrical components, the pulse capacitor stands out. Imagine it as a tiny energy bank. It patiently absorbs the charging energy from a small - power supply over a certain period. When the need arises, it springs into action, releasing all that stored energy in the blink of an eye. This quick release creates a powerful impact current and a surge of energy. It's a key player in high - voltage impulse discharge tests, high - energy physics experiments, oscillation circuits, and geological exploration.
Model Description
Example: XHCC-4/35 pulse capacitor
1. 4--Rated capacitance 4uF
2. 35--Rated voltage level 35kV
| N.o | model | Rated voltage | Rated capacity | Interpolar withstand voltage | Application |
| 01 | 3/2000 | 3kV | 2000uF | 3.6kV | Impulse discharge |
| 02 | 6.5/100 | 6.5kV | 100uF | 3.6kV | Impulse discharge |
| 03 | 6.5/200 | 6.5kV | 200uF | 7.5 kV | Impulse discharge |
| 04 | 6.5/500 | 6.5kV | 500uF | 7.5 kV | Impulse discharge |
| 05 | 15/8 | 15kV | 8uF | 17.5 kV | Impulse discharge |
| 06 | 15/8*2 | 15kV | 8uF | 17.5 kV | Impulse discharge |
| 07 | 15/8*3 | 30kV | 2uF | 34.5 kV | Impulse discharge |
| 08 | 35/2 | 35kV | 2uF | 39.5 kV | Impulse discharge |
| 09 | 35/4 | 35kV | 4uF | 39.5 kV | Impulse discharge |
| 10 | 30/4 | 30kV | 4uF | 34.5 kV | Impulse discharge |
| 11 | 40/4 | 40kV | 4uF | 45 kV | Impulse discharge |
| 12 | 40/6 | 40kV | 6uF | 45 kV | Impulse discharge |
| 13 | 100/1 | 100kV | 1uF | 110 kV | Impulse discharge |
